UV3060 2pc EPSON XP600 UV Printer Brochure

short description:

1. Using 2pcs XP600 Printer Head: High precision & Stability, Easy to maintain, Faster speed;
2. Max  Print Height: 180mm;
3. Print CMYK, W and Varnish at the same time;
4. Rotary jig is equipped;
5. Universal Printer: can print almost all flat items except textile.


Product Detail

Machine Specification

Product Tags


It’s easy to see why UV printing has overtaken traditional water and solvent-based thermal drying techniques and why it is expected to continue growing in popularity. Not only does the method speed up production – meaning more is done in less time – rejection rates are reduced as the quality is higher. Choosing UV printing over traditional printing methods could be the difference between producing a luxury product, and something that feels much less superior


  • Previous:
  • Next:

  • Name Digital UV Flatbed Printer UV3060
    Model No. UV3060
    Machine Type Automatic, Flatbed, UV LED Lamp, Digital Printer
    Printer Head 2pcs Epson XP600 Print Head
    Max Print Size 11.81″*23.62” (30x60cm)
    Max Print Height 180mm
    Materials to Print Rotary , Metal, Plastic, Glass, Wood, Ceramics, Acrylic, Leather, etc,
    Printing Method Drop-on-demand Piezo Electric Inkjet
    Printing Direction Unidirectional Printing or Bi-directional Printing Mode
    Printing  Resolution 1:720x720dpi_4pass   2:1440x720dpi_8pass      3:1440x1440dpi_16pass
    Printing  Quality True Photographic Quality
    Nozzle Number 1600
    Ink Colors CMYKW and Varnish
    Ink Type UV Ink
    Ink Supply 100ml/Bottle
    Printing  Speed A3:6pass+360*1080+ Bi Direction+Edsion80% Strong A:3’35″ 2.14sqm/hA3:8pass+720*720+ Bi Direction+Edsion80% Strong A:4’45″ 1.6sqm/hA3:12pass+720*1080+ Bi Direction+Edsion80% Strong A:7’08″ 1sqm/h
    File Format PDF,JPG,TIFF,EPS,AI,etc
    Height Adjustment Manual
    Media Feeding System Manual
    Max Media Weight 30 KG
    Operating System WINDOWS 7/WINDOWS 8/WINDOWS 10
    Interface USB3.0
    Software Maintop
    Languages Chinese/English
    Voltage 110V/ 220V
    Power Consumption 800w
    Working Environment 20-28 Degrees.
    Package Type Wooden Case
    Machine Size 680*600*650
    Net Weight 64kgs
    Gross Weight 100kg
    Packing Size 1040*880*800mm
    Price Includes Printer,software, Inner six angle wrench, Small screwdriver, Ink absorption mat, USB cable, Syringes, Damper, User manual, Wiper, Wiper Blade, Mainboard fuse, Replace screws and nuts
