UV3060 2pc EPSON XP600 UV Printer Brochure
It’s easy to see why UV printing has overtaken traditional water and solvent-based thermal drying techniques and why it is expected to continue growing in popularity. Not only does the method speed up production – meaning more is done in less time – rejection rates are reduced as the quality is higher. Choosing UV printing over traditional printing methods could be the difference between producing a luxury product, and something that feels much less superior
| Name | Digital UV Flatbed Printer UV3060 |
| Model No. | UV3060 |
| Machine Type | Automatic, Flatbed, UV LED Lamp, Digital Printer |
| Printer Head | 2pcs Epson XP600 Print Head |
| Max Print Size | 11.81″*23.62” (30x60cm) |
| Max Print Height | 180mm |
| Materials to Print | Rotary , Metal, Plastic, Glass, Wood, Ceramics, Acrylic, Leather, etc, |
| Printing Method | Drop-on-demand Piezo Electric Inkjet |
| Printing Direction | Unidirectional Printing or Bi-directional Printing Mode |
| Printing Resolution | 1:720x720dpi_4pass 2:1440x720dpi_8pass 3:1440x1440dpi_16pass |
| Printing Quality | True Photographic Quality |
| Nozzle Number | 1600 |
| Ink Colors | CMYKW and Varnish |
| Ink Type | UV Ink |
| Ink Supply | 100ml/Bottle |
| Printing Speed | A3:6pass+360*1080+ Bi Direction+Edsion80% Strong A:3’35″ 2.14sqm/hA3:8pass+720*720+ Bi Direction+Edsion80% Strong A:4’45″ 1.6sqm/hA3:12pass+720*1080+ Bi Direction+Edsion80% Strong A:7’08″ 1sqm/h |
| File Format | PDF,JPG,TIFF,EPS,AI,etc |
| Height Adjustment | Manual |
| Media Feeding System | Manual |
| Max Media Weight | 30 KG |
| Operating System | WINDOWS 7/WINDOWS 8/WINDOWS 10 |
| Interface | USB3.0 |
| Software | Maintop |
| Languages | Chinese/English |
| Voltage | 110V/ 220V |
| Power Consumption | 800w |
| Working Environment | 20-28 Degrees. |
| Package Type | Wooden Case |
| Machine Size | 680*600*650 |
| Net Weight | 64kgs |
| Gross Weight | 100kg |
| Packing Size | 1040*880*800mm |
| Price Includes | Printer,software, Inner six angle wrench, Small screwdriver, Ink absorption mat, USB cable, Syringes, Damper, User manual, Wiper, Wiper Blade, Mainboard fuse, Replace screws and nuts |
